Ninebot Kickscooter MAX | ||
---|---|---|
Unfold: Length x width x height | -45.9 x 18.6 x 47.4 in (1167 x 423 x 1203 mm) | |
Fold: Length x width x height | -45.9 x 18.6 x 21.0 in (1167 x 423 x 534 mm) | |
Net Weight | Approx. 41.2 lbs (18.7 kg) | |
Payload | 66.1-220.5 lbs (30.0-100.0 kg) | |
Tires | Air Filled | |
Suspension | None | |
Recommended Age | 14+ years | |
Required Height | 3'11"-6'6" (120-200 cm) | |
Max. Speed | 18.6mph (*Top speed may be impacted by battery level, environmental temperature and available traction.) | |
Typical Range | Approx. 40.4 miles (65 km) | |
Max. Slope | Approx. 20% | |
Traversable Terrian | asphalt/flat pavement: obstacles < 0.4 in (1 cm); gaps < 1.2 in (3 cm) | |
Operating Temperature | 14-104ºF (-10-40ºC) | |
Storage Temperature | -4-122ºF (-20-50ºC) | |
IP Rating | IP54 | |
Duration of Charging | ~ 6 h | |
Nominal Voltage | 36 VDC | |
Max. Charging Voltage | 42 VDC | |
Charging Temperature | 32-104ºF (0-40ºC) | |
Nominal Capacity | 551 Wh | |
Battery Management System | Over-heating, short circuit, over-current and over-charge protection | |
Number of Batteries | 1 | |
Nominal Motor Power | 350 W | |
Output Power | 121 W | |
Input Voltage | 100-240V ~ 50/60Hz | |
Output Voltage | 42 VDC | |
Output Current | 2.9 A | |
Brake Light | LED rear light | |
Riding Modes | Energy Saving mode, Standard mode and Sport mode | |
Ninebot MAX Series Manual | Download User Manual Here |
