RFloXa Hawk 31 PRO Front Fork –

203mm or 228mm Travel

Advanced E-Moto Suspension for

Surron, Talaria & More...

Built for high-speed hits, downhill drops, and fast-paced e-moto terrain, the RFloXa Hawk 31 PRO Front Fork is a true upgrade for electric dirt bikes and high-performance e-bikes. With 203–228mm of travel, precision CNC machining, and independent oil-spring damping per leg, this fork delivers competition-grade adjustability with rugged reliability.

From urban jumps to forest trails, the Hawk 31 PRO offers smooth action, customizable tuning, and serious bottom-out support — all in a package engineered for the demands of electric performance.

🛠 Key Features:

• Travel Range: 203mm or 228mm (19” or 21” wheel compatible)

• Stanchion Diameter: 37mm

• Caliper Mount Spacing: 74mm (compatible with 203mm discs; 220mm upgradeable)

• CNC Precision-Machined Triple Clamp

• Inverted oil-spring damping system with asymmetrical leg design

• Multi-stage adjustments:

  • High-speed compression

  • Low-speed compression

  • Rebound

  • Spring preload

• Bottom-out control via oil pressure support

• Dual compression valve plates for reliable damping

• Low-friction, low-freeze shock oil for consistent performance

• Built from AL6061-T6 and AL7075-T6 aluminum

• Uses 55CRSI spring wire for long-term resilience

⚖️ Spring Rate Options:

203mm Version (For 19” Front Wheels)

• 45 lb spring – Up to 100kg / 220 lbs (Special Order)

• 60 lb spring – 100–130kg / 220–285 lbs (Stocked)

• 45–60 lb Progressive Spring – 80–130kg / 175–285 lbs (Stocked)

228mm Version (For 19” or 21” Front Wheels)

• 45 lb spring – Up to 100kg / 220 lbs (Stocked)

• 55 lb spring – 100–130kg / 220–285 lbs (Stocked)

Note: The 228mm version raises bar height slightly due to extended travel.

✅ Fitment Compatibility:

• Surron LBX / LBS / L1E

• Talaria Sting MX3 / MX4 / XXX

• Segway X160 / X260

• E-Ride Pro S / SS 2.0 / SS 3.0 / SR

• 79-Bike Falcon M

• Rerode R1

• RAWRR Mantis

⚠️ Important Notes (Front Fork Only):

• Currently not plug-and-play with larger brake calipers found on:

  • Altis Sigma

  • SRPNT Moto

  • E-Ride Pro SS 3.0

  • E-Ride Pro SR

These bikes require a brake adapter that is not yet available, but it’s currently in development. If you’re using Volar Sport Racing calipers, we can special order a front adapter for you—just reach out and we’ll get you set up.

🧠 FAQ

Q: How does the Hawk 31 PRO compare to other suspension forks?

A: Unlike basic forks that only offer minimal rebound or preload, the Hawk 31 PRO gives you true multi-stage damping control with separate high-speed and low-speed compression adjustments. This lets you fine-tune your ride for everything from fast chatter to heavy landings.

Q: Why is spring preload adjustability so important?

A: Spring preload lets you balance the fork’s stiffness based on your weight and riding conditions. Compared to models like the Fastace ALX13RC, the Hawk 31 PRO’s multi-stage preload system offers finer control—ideal for performance tuning in both casual and extreme terrain.
