Apollo RFN Ares Rally DLX Electric Dirt Bike | 43ah battery | With headlight (Latest 2024 Model)

Name: Apollo RFN Ares Rally DLX Electric Dirt Bike | 43ah battery | With headlight (Latest 2024 Model)
Brand: RFN
SKU: P-R-1768
Price: 4399.0 USD
Availability: InStock

Apollo RFN Ares Rally DLX Electric Dirt Bike | 43ah battery | With headlight (Latest 2024 Model)

$4,399.00

~~$5,099.00~~ $4,399.00

Sale Sold out

Please contact us to price match. Shipping is calculated at checkout

Color Black W/ Red Black w/ Grey White w/red

Product variants

Quantity

FAST SHIPPING. 2-YEAR WARRANTY.

Introducing the Apollo RFN Ares Rally DLX Electric Dirt Bike - This is Apollo's answer to the electric dirt bike. NOW WITH A HEADLIGHT! Top speed 20mph, range of up to 100 miles, and a 12.5Kw motor, the RFN Ares is a real dirt bike with a powerful electric drivetrain. This is the 2023 model with the rectangle display. this has the Headlight with larger battery.

CITY RANGE : 100MILES
PEAK POWER: 12.5KW
CURB WEIGHT: 154LBS
BATTERY: 74V 43AH
SHOCK ABSORBERS: 200MM
TOP SPEED: 20mph

POWER

11-58T Max Torque 305 N·m (Max Torque of rear wheel: 305 / N-m

Battery

43ah 74V, LG Premium 21700 lithium cells, removable, can be charged on a bike or separately.

Brakes

Front and Rear 4-piston hydraulic disc, 210mm

Charging

2-3h with Quick Charge Function

Controller

Sine wave, Best-in-class power density, and state-of-the-art motor control algorithms.

Electric motor

Air-cooled Permanent Magnet Synchronous Motor, energy regeneration function, Direct drive, 420

Ships in 3-5 business days arrives from there in 3-5 business days.

Drivetrain

Electric motor: Air cooled Permanent Magnet Synchronous Motor, energy regeneration function, Direct drive, 420 chains with DX

Sprocket: 13T-58T

Rated power: 5 kW

Peak power: 12.5 kW**

Max Torque of motor: 58 N·m

Max Torque of rear wheel: 305 N·m

Dimensions

Fork angle: 340mm - 13.39''

Offset: 15mm in triple clamps, 45mm in forks.

Seat height: 860mm - 33.86''

Trail: 111mm - 4.37''

Wheelbase: 1330mm - 52.36''

Fenders & Bodywork

Material: PP/ABS plastic

Frame

Build: 6082 aluminum extruded, forged, CNC machined, and steel frame.

Front Suspension

Upside Down, 200mm travel, Fully adjustable

Handlebar

6061 aluminum, 760mm length

Rear Suspension

Mono-Shock, 74mm travel, adjustable

Regulatory

Certificate: CE

Ride modes

Mode 1: Tortoise mode: The ultimate mode of energy conservation exploration. Limited to 25 km/h with 3.5 hours battery range.

Mode 2: Rabbit mode: Enduro or active trail riding. 1-2 h riding time.

Mode 3: Rocket mode: Track and race mode, maximal torque and speed, riding time up to 60 Sec.

Mode 4: Reverse mode: Limited to 9 km/h.

Speed & Range

Range: 160 Km (Test data Load: 75 Kg, 20 Km/h uniform speed, ambient temperature: 25 °C, flat pavement, standard tires, standard tire pressure)

Weight

N.W of Battery: 15 kg

N.W of the whole bike: 68 kg

Max load: 120kg

Wheels & Tires

Hubs: Forged and CNC aluminum RFN hubs with 20mm axle.

Rims: F 19"/ R 18" (Motorcycle standard) re-enforced, triple chamber, 7050 aluminum.

Tires: F: CST CM721 70/100-19 off-road, R: CST CM722 90/100-18 off-road

*Top Speed Information

Off-road Top Speed:

NOTICE: This personal electric vehicle (PEV) comes factory set to “City Mode” with a maximum on-road speed of 20 mph, in compliance with common city and state regulations, making it suitable for use on public roads, sidewalks, bike paths, and city parks. Activating off-road or track mode will increase vehicle performance and top speed, but please note that your PEV may no longer be legal for street use in this mode. It’s essential to check and follow all applicable local laws and regulations when riding.

Click here to learn how to enable off-road/mode.

Click here to learn more about City Mode and Off-Road Mode

Warranty

This vehicle comes with a 24-month limited warranty against factory defects.

At REV Rides we understand the importance of micromobility. Many of our customers rely on their electric vehicles for transportation to work, school or just daily recreation. Because of this we want to ensure that our customers feel secure with their purchase from us.

Click here to learn more about our warranty

View full details

Apollo RFN Ares Rally Pro Electric Dirt Bike

Battery
74V / 2480Wh, LG Premium 21700 lithium cells, removable, can be charged in bike or separately.

Brakes
Front and Rear 4-piston hydraulic disc, 210mm

Charging
2-3h with Quick charge function

Controller
Sine wave, Best-in-class power density and state-of-the-art motor control algorithms.

Drivetrain

Electric motor: 12.5KW Brushless Motor. Air cooled Permanent Magnet Synchronous Motor, energy regeneration function, Direct drive, 420 chain with DX
Sprocket: 11-58T
Rated power: 5 kW
Peak power: 12.5 kW**
Max Torque of motor: 58 Nm
Max Torque of rear wheel: 305 Nm

Dimensions

Fork angle: 340mm - 13.39''
Offset: 15mm in triple clamps, 45mm in forks.
Seat height: 860mm - 33.86''
Trail: 111mm - 4.37''
Wheel base: 1330mm - 52.36''

Fenders & Bodywork
Material: PP/ABS plastic

Frame
Build: 6082 aluminum extruded, forged, CNC machined and steel frame.

Front suspension
Upside Down, 200mm travel, Fully adjustable

Handlebar
6061 aluminium, 760mm length

Rear suspension
Mono-Shock, 74mm travel, adjustable

Regulatory
Cetificate CE

Ride modes

Mode 1, Tortoise mode: The ultimate mode energy conservation exploration. Limited to 15.5mph
Mode 2, Rabbit mode: Enduro or active trail riding.
Mode 3, Rocket mode: Track and race mode, maximal torque and speed
Mode 4, Reverse mode: Limited to 6mph.

Range
100 miles (Test data Load: 165lbs, 13mph uniform speed, ambient temperature: 25 °C, flat pavement, standard tires, standard tire
pressure)

Top Speed 20mph

Weight

N.W of whole bike 149lbs
N.W of Battery 33lbs

Max load
265lbs

Wheels & Tires

Hubs: Forged and CNC aluminum RFN hubs with 20mm axle.
Rims: F 19"/ R 18" (Motorcycle standard) re-inforced, triple chamber, 7050 aluminum.
Tires: F: CST CM721 70/100-19 off-road , R: CST CM722 90/100-18 off-road
